150W DC-DC Step-Up Boost Converter 10-32V to 12-35V 6A Adjustable Power Supply Module
Description:
ChatGPT
The 150W DC-DC Step-Up Boost Converter is a versatile and efficient power supply module designed to increase the voltage from a lower DC input to a higher DC output. This module is ideal for applications requiring a stable, adjustable voltage higher than the input, with a significant current capability of up to 6A.
Description
Key Features:
- Input Voltage Range: 10V to 32V DC.
- Output Voltage Range: Adjustable from 12V to 35V DC.
- Output Current: Up to 6A, with a maximum output power of 150W.
- Efficiency: High conversion efficiency, typically over 90%.
- Protection: Includes features like over-current protection, over-temperature protection, and short-circuit protection.
- Adjustability: Both voltage and current are adjustable via multi-turn potentiometers.
- Heat Dissipation: Equipped with a heat sink for improved thermal management during high-power operation.
Specifications:
- Input Voltage: 10V to 32V DC
- Output Voltage: 12V to 35V DC (adjustable)
- Output Current: Maximum 6A
- Output Power: Maximum 150W
- Conversion Efficiency: Up to 95% (depending on input/output voltage and current)
- Ripple Frequency: Low ripple and noise
- Size: Approximately 60mm x 52mm x 22mm
Usage Instructions
1. Input Connection:
- Connect the input power supply to the module’s input terminals (IN+ and IN-). Ensure correct polarity: the positive terminal goes to IN+ and the negative terminal to IN-.
2. Output Connection:
- Connect the device or load to be powered by the module to the output terminals (OUT+ and OUT-). Ensure correct polarity: the positive terminal goes to OUT+ and the negative terminal to OUT-.
3. Adjusting Output Voltage:
- Use a multimeter to measure the output voltage.
- Adjust the output voltage by turning the voltage adjustment potentiometer (typically a blue multi-turn potentiometer). Turn clockwise to increase the voltage and counterclockwise to decrease it.
4. Adjusting Output Current:
- Set the desired current limit by turning the current adjustment potentiometer.
- Monitor the current using a multimeter connected in series with the load. Adjust the potentiometer to the required current limit.
5. Powering On:
- Once all connections are secure and adjustments are made, turn on the input power supply.
- Check the output voltage and current to ensure they are within the desired range.
6. Load Connection:
- Connect your load to the output. The module should provide a stable, regulated voltage as per your adjustments.
7. Thermal Management:
- Ensure adequate ventilation around the module, especially when operating near the maximum power output.
- The heat sink helps dissipate heat, but additional cooling may be necessary for continuous high-power operation.
Applications
- Battery-Powered Projects: Step up voltage from battery packs for higher voltage applications.
- DIY Electronics: Ideal for hobbyists and DIY electronics projects requiring adjustable voltage levels.
- Solar Power Systems: Boost voltage from solar panels to charge batteries or power devices.
- Automotive: Step up 12V battery voltage to power 24V or higher voltage devices.
- Laboratory Use: Versatile adjustable power supply for experiments and testing.
By following these instructions and leveraging the features of the 150W DC-DC Step-Up Boost Converter, you can efficiently convert and regulate voltage for a wide range of applications, ensuring stable and reliable power delivery.
