Speed Measuring Sensor Groove Coupler Module For Arduino
Description:
Speed Measuring Sensor Groove Coupler Module is a specialized sensor designed for accurately measuring the rotational speed (RPM) of rotating objects. This sensor is commonly used in Arduino-based projects for monitoring the speed of motors, fans, wheels, and other moving parts in various applications such as robotics, automation, and DIY electronics projects. It is particularly useful when integrating with Arduino systems to track and control the speed of mechanical systems in real-time.
The sensor operates based on optical sensing technology, where it detects the passage of a target object through an optical sensor. This setup enables the module to measure the rotational speed of a wheel or motor shaft by counting the number of interruptions in the light beam, which corresponds to the number of rotations or partial rotations of the object.
Features:
1. Optical Sensing Technology
2. Groove Coupler Module
3. Rotational Speed Measurement
4. High Precision and Reliability
5. Easy Integration with Arduino
6. Adjustable Sensitivity
7. Compact and Durable Design
Diagram:
Specifications:
| Operating Voltage | 3.3V to 5V DC |
| Interface | Grove interface |
| Sensor Type | Magnetic Hall Effect |
| Output Signal | Digital pulse signal |
| Detection Range | 1 RPM to 100,000 RPM |
| Cable Length | 20cm to 50cm |
| Dimensions | 50mm x 40mm |
| Weight | 15g |
| Temperature Range | -20°C to 60°C |
