NE555 Delay Timer Switch Adjustable 0-10 Sec 5V Relay Module
Description:
NE555 is a popular timer IC that can be used to create various types of timing circuits, including delay timer switches. When combined with a relay module, it can control high-power loads based on timing intervals. Here's how you can use an NE555 delay timer switch with an adjustable 0-10 second timing range and a 5V relay module:
Features:
1. Adjustable Delay Time (0-10 Seconds)
2. NE555 Timer IC
3. 5V Operation
4. 5V Relay Output
5. Wide Application Range
6.Simple Interface
7. Low Power Consumption
8. Triggering Mechanism
9. Compact Design
10. Indicator LED
Diagram:
Specifications:
| Chip Used | NE555 Chip |
| Input voltage | 6V |
| Adjustable time | 0-10sec |
| AC Control voltage | 250V/max. 10A |
| DC Control Voltage | 30V/max. 10A |
| Dimensions | 3 x 2 x 1cms |
| Weight | 5 grams |
| Voltage | 5V DC |
| Delay Time | 0 to 10 sec |
| Current Consumption | 10-15mA |
