1.8V-12V 2A DC Motor PWM Speed Regulator
Description:
1.8V-12V 2A DC Motor PWM Speed Regulator is a versatile and efficient electronic device designed to control the speed of DC motors by adjusting the PWM (Pulse Width Modulation) signal. This module is commonly used in various applications, including robotics, home automation, RC models, electric vehicles, and industrial machines, where precise motor speed control is required. The module supports a wide input voltage range from 1.8V to 12V, making it suitable for a variety of small to medium DC motors.
Features:
1. Wide Input Voltage Range
2. 2A Current Rating
3. Pulse Width Modulation (PWM) Speed Control
4. Adjustable Speed Control via Potentiometer
5. High Efficiency
6. Thermal Protection
7. Compact and Easy to Use
8. Widely Compatible
9. Reverse Polarity Protection
Diagram:
Specifications:
| Input Voltage Range | 1.8V to 12V DC |
| Output Current | Up to 2A |
| Maximum Power | 24W (12V x 2A) |
| Operating Temperature | -40°C to +85°C |
| Dimensions | ~45mm x 30mm x 25mm |
