MAX485 TTL to RS485 Converter Module
Description:
MAX485 TTL to RS485 Converter Module is a compact and highly effective interface designed to allow communication between devices using TTL (Transistor-Transistor Logic) level signals and RS485 differential signals. This module is often used for serial communication between microcontrollers, embedded systems, and industrial equipment. It’s particularly useful when long-distance data transmission and higher noise immunity are required.
Features:
1. High-Speed Data Transmission
2. Low Power Consumption
3. Long-Distance Communication
4. Multi-Point Communication
5. Differential Signaling
6. TTL to RS485 and RS485 to TTL Conversion
7. Easy Integration
8. Half-Duplex Communication
9. Compact and Low-Cost
10. RS485 Bus Termination
Diagram:
Specifications:
| Operating Voltage | 5V DC |
| Output Voltage | ±5V to ±12V |
| Maximum Data Rate | 2.5 Mbps |
| Maximum Communication Distance | 1200 meters |
| Low Power Consumption | 120 µA |
| Temperature Range | -40°C to +85°C |
| Size | 30mm x 20mm |
